The CH690 DIGITAL WH is designed with beauty and adaptability in mind. featuring a semi-glass panel that offers an expansive view of installed components. For those seeking enhanced performance. the rear of the case supports DIY modifications. allowing users to replace the semi-glass panel with a mesh panel and fan bracket to boost horizontal airflow. Additionally. the integrated light strip slot enables the addition of light strips to create an immersive gaming atmosphere. blending aesthetics with functionality for a truly personalized setup.

YES IT FITS
The CH690 DIGITAL WH is engineered for exceptional versatility. accommodating a 180mm PSU and a 450mm GPU with ease. It features up to 8 individual removable expansion slots. providing flexibility for various configurations. Storage options include 1 x 3.5"" drive bay and 2 x 2.5"" drive bays. ensuring ample space for data needs. This case is designed to support a wide range of components. making it an ideal choice for either gaming and professional setups.

DYNAMIC PERFORMANCE AT A GLANCE
The CH690 DIGITAL WH case features a cutting-edge digital display that offers real-time monitoring of system's vital statistics. With switchable modes for CPU. GPU. and PSU. effortlessly track temperature in Fahrenheit or Celsius. power consumption. usage. and frequency. The CPU mode also includes fan speed monitoring. while the PSU mode provides additional insights into fan performance. This sophisticated display transforms the system into a high-tech command center. allowing optimal performance and efficiency at a glance.

COOLING VERSATILITY
The CH690 DIGITAL WH is designed to adapt to versatile configurations. ensuring efficient heat dissipation through its innovative mesh-designed PSU shroud that creates a vertical airflow channel. It accommodates a wide range of radiator sizes. including up to 420mm on the top. 280mm on the side. and 360mm within the PSU shroud. Additionally. it supports various fan configurations. allowing for up to 3×140mm fans on the top. side. and PSU shroud. along with a 140mm fan at the rear. With the capability to support CPU coolers up to 182mm in height. the CH690 DIGITAL WH is engineered to maintain optimal temperatures for high-performance systems.

Design
Material: Acrylonitrile butadiene styrene (ABS). SPCC. Tempered glass
Form factor: Tower
Type: PC
Product colour: White
Supported motherboard form factors: ATX. micro ATX. Mini-ITX
Number of 3.5" bays: 1
Number of 2.5" bays: 3
Number of expansion slots: 8
Feature: Side window
Suitable for: Gaming
Feature: Tempered glass panel(s)
Feature: Cable management
Feature: Reset button
Feature: On/off button
Maximum CPU cooler height: 18.2 cm
Maximum graphics card length: 45 cm
Maximum PSU length: 18 cm
Power supply
Power supply location: Bottom
Supported power supply form factors: ATX. PS2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Feature: Combo headphone/mic port
Display
Feature: Built-in display
Display type: LCD
Cooling
Number of side fans supported (max): 3
Side fans diameters supported: 120.140 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 120 mm
Number of top fans supported (max): 3
Top fans diameters supported: 120.140 mm
Number of bottom fans supported (max): 3
Bottom fans diameters supported: 140 mm
Feature: Liquid cooling capability
Side radiator sizes supported: 120.140.240.280 mm
Bottom radiator sizes supported: 120.240.360 mm
Top radiator sizes supported: 120.140.240.280.360.420 mm
Storage
Supported HDD sizes: 2.5.3.5"
SSD form factor: 2.5"
Weight & dimensions
Width: 240 mm
Depth: 481 mm
Height: 516 mm
Weight: 9.8 kg
