AJAX BASELINE SpeakerPhone White

Product code: 17732220 // MPN: 87530.180.WH1

New entry

€210,24 (inc. VAT)

Available from 1 to 3 days

Add to wishlist

Dahua PIR Outdoor Camera Detector ARD2251E-W2

Code: 17724820

€293,76

Available from 1 to 3 days

SpeakerPhone Jeweller is a voice module designed for quick audio alarm verification via direct voice calls between a monitoring company and a secured site. The device provides clear and secure full duplex voice communication using the VoRF1 proprietary audio streaming protocol and AI technologies. In case of an alarm, a central monitoring station (CMS) operator can immediately contact the facility to speak with someone on the spot or listen to what is happening. The operator assesses the situation and takes the right action — and only when the threat is real. Also, operators can use SpeakerPhone Jeweller to deter intruders or respond to auxiliary alarms.

Communication
VoRF communication technology
Proprietary wireless audio streaming protocol using time division duplex.

Key features:

Two-way communication.
Advanced sabotage protection.
Full duplex audio communication.
Radio communication range
up to 1,700 m
Between the device and a hub in an open space.
Frequency band : 863.0–865.0 MHz

Jeweller communication technology
Proprietary wireless communication technology to transmit commands, alarms, and events.

Key features:

Two-way communication.
Advanced sabotage protection.
Block encryption featuring a dynamic key.
Instant notifications.
Remote control and configuration in Ajax apps.
Frequency bands : 866.0–866.5 MHz / 868.0–868.6 MHz / 868.7–869.2 MHz
Maximum effective radiated power (ERP) : up to 25 mW
Automatic power control to reduce power consumption and radio interference.
Radio signal modulation : GFSK
Radio communication range : up to 1,700 m Between the device and a hub in an open space.

AI-powered sound optimization
It provides:

Clear voice transmission.
Suppression of extraneous noise.
Improved audibility even at long distances.
Option to set up the AI feature in Ajax apps.
Voice audibility : up to 10 m

Auto adjustment of the microphone sensitivity.

Output speaker power : 3 W
Speaker volume : up to 103 dB / 83 dB at a distance of 1 m.
Frequency range : from 200 Hz to 16 kHz
Audio codec : Opus

Remote firmware update

When a new firmware is available, an admin or PRO with the rights to configure the system can run the update in Ajax apps.

The hub must be connected to Ajax Cloud via Ethernet or Wi-Fi.

Sabotage protection

Tamper alarm
Notifications on attempts to detach the device from the surface.
Microphone cut-off detection
Notifications of attempts to damage an in-built microphone.

Power supply

Battery : 4 × CR123

Pre-installed.

Calculated battery life : up to 3 years

In a standby mode. : up to 12 hours

Optional external power supply : 12 V⎓, 1 A

The power supply cable length should not exceed 10 m when using the 2 × 0.35 copper-conductor cable. When the external power supply is connected, the batteries operate as a backup power source.

Dimensions : 112 × 112 × 42 mm
Weight : 270 g
Operating temperature range : from 0 °C to +40 °C
Operating humidity : up to 75%
Protection class : IP50
