POWER SUPPLY (PSU)

The EON Series offers high quality and 80 PLUS® 230V EU efficiency at highly competitive pricing. equipped with silent 120mm fans.

The power supplies are fully built from steel. coated in elegant black. and equipped with extra-long native cables. The EON Series runs quietly and provides its power with all essential protection and safety features.

Power
Total power: 500 W
AC input voltage: 200 - 240 V
AC input frequency: 50 Hz
Input current: 3.5 A
Power factor: 0.9
Power Factor Correction (PFC) type: Active
Combined power (+3.3V): 100 W
Combined power (+12V): 444 W
Combined power (+5V): 100 W
Combined power (-12V): 4.8 W
Combined power (+5Vsb): 12.5 W
Max output current (+3.3V): 20 A
Max output current (+12V1): 37 A
Max output current (+5V): 20 A
Max output current (-12V): 0.4 A
Max output current (+5Vsb): 2.5 A
Power protection features: Short circuit. Surge and inrush. Surge protection
Ports & interfaces
Motherboard power connector: 20+4 pin ATX
Motherboard power cable length: 65 cm
Number of SATA power connectors: 4
SATA power cable length: 450.600.750 mm
Peripheral (Molex) power connectors (4-pin): 2
Peripheral (Molex) power cable length: 150.450 mm
Feature: EPS power connector (4+4 pin)
PCI Express power connectors (6+2 pin): 1
Feature: CPU power connector (4+4 pin)
Feature: ATX power connector (20+4 pin)
Cabling type: Non-Modular
Performance
80 PLUS certification: 80 PLUS
Supported motherboard form factors: ATX
Purpose: PC/Server
Power supply unit (PSU) form factor: ATX
ATX version: 2.3
Design
Product colour: Black
Cooling type: Active
Fan diameter: 12 cm
Feature: On/off switch
Certificates
Compliance certificates: CB. CE. EAC. RoHS
Weight & dimensions
Width: 150 mm
Depth: 140 mm
Height: 86 mm
Weight: 1.2 kg
Packaging data
Package weight: 1.45 kg
Package type: Box
Technical details
Sustainability certificates: ErP
Logistics data
Warranty period: 2 year(s)
