COMPONENTS FOR SERVERS

Processor
Processor manufacturer: AMD
Processor socket: Socket AM4
Compatible processor series: AMD Ryzen™ 3. AMD Ryzen™ 5
Supported processor sockets: Socket AM4
Memory
Supported memory types: DDR4-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Memory voltage: 1.2 V
ECC сompatibility: ECC & Non-ECC
Supported memory clock speed (max): 3200 MHz
Maximum internal memory: 128 GB
Storage controllers
Supported storage drive interfaces: PCI Express 3.0. PCI Express 4.0. SATA
Feature: RAID support
RAID levels: 0. 1. 10
Graphics
Feature: On-board graphics card
Graphics card family: ASPEED
Graphics card: AST2500
Internal I/O
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Number of SATA III connectors: 4
Feature: Chassis intrusion connector
Number of COM connectors: 1
Feature: TPM connector
Rear panel I/O ports
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 4
Feature: IPMI LAN (RJ-45) port
VGA (D-Sub) ports quantity: 1
HDMI ports quantity: 1
Network
Feature: Ethernet LAN
Ethernet interface type: 10 Gigabit Ethernet. Gigabit Ethernet
LAN controller: Intel I210. Intel X710-AT2
Features
Motherboard chipset: AMD B550
Product colour: Green
PC health monitoring: Fan. Temperature. Voltage
Component for: Server
Motherboard form factor: mini ITX
Motherboard chipset family: AMD
Cooling type: Passive
Power source type: ATX. DC
Expansion slots
PCI Express x16 (Gen 4.x) slots: 1
PCI Express OCuLink connectors (NVMe support): 1
Number of M.2 (M) slots: 1
BIOS
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 5.1
Operational conditions
Operating temperature (T-T): 10 - 35 °C
Weight & dimensions
Width: 170.2 mm
Depth: 208028 mm
