PC CASE

With its futuristic look. a tempered-glass side panel. and an air-permeable mesh front. the AK5M RGB is the ultimate home for powerful high-end hardware. The inside of this ATX case has been spaciously designed and offers room for up to eleven fans or two radiators. In addition. modern input-output connections and support for the new BTF mainboards will all ensure that the case stays future-proof.

Futuristic Look with Strong Airflow
With its tempered-glass side panel and mesh front. the AK5M RGB is ideal for showcasing the installed hardware as well as keeping it continually cooled.

Four Pre-Installed Fans
Four 120 mm RGB PWM fans are pre-installed in the AK5M RGB. and each fan has three rows of encircling LED illumination to provide striking highlights. Up to eleven fans will find room in the case.

Dual-Radiator Support
If water cooling is preferred instead of air cooling. then the AK5G RGB is exactly what you're looking for. as the case allows the simultaneous operation of up to two 360 mm radiators.

Ideal Connections
To connect a wide range of mobile and peripheral devices. the AK5M RGB has a modern TRRS and USB-C port on the front of the top panel. In addition. a controller provides the connection and operation of up to four RGB LED components and four PWM fans.

Spacious Design Inside
With an available space of up to 41 cm. even large graphics cards can be accommodated inside the AK5M RGB. In addition. CPU coolers with a height of up to 17 cm can be installed. as well as power supply units with a length of up to 23.5 cm. And there is installation space for up to two 3.5" HDDs or four 2.5" SSDs.

Design
Form factor: Midi Tower
Type: PC
Product colour: Black
Supported motherboard form factors: ATX. micro ATX. Mini-ITX
Number of 3.5" bays: 2
Number of 2.5" bays: 4
Number of expansion slots: 7
Feature: Side window
Feature: Illumination
Illumination colour: Multi
Illumination location: Case fans
Feature: Tempered glass panel(s)
Feature: Anti-dust filter
Feature: Cable management
Feature: On/off button
Feature: RGB control button
Maximum CPU cooler height: 17 cm
Maximum graphics card length: 41 cm
Maximum PSU length: 23.5 cm
Ports & interfaces
Feature: Audio input
Feature: Audio output
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
ARGB ports quantity: 4
Cooling
Front fans installed: 3x 120 mm
Number of front fans supported (max): 3
Front fans diameters supported: 120 mm
Number of side fans supported (max): 2
Side fans diameters supported: 120.140 mm
Rear fans installed: 1x 120 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 120 mm
Number of top fans supported (max): 3
Top fans diameters supported: 120.140 mm
Number of bottom fans supported (max): 2
Bottom fans diameters supported: 120 mm
Feature: Liquid cooling capability
Storage
Supported HDD sizes: 2.5.3.5"
Weight & dimensions
Width: 225 mm
Depth: 465 mm
Height: 485 mm
