DISPLAYPORT

The equip® DisplayPort Cable is a digital audio and video cable. designed primarily for connections between computer and its display monitor. or a computer and a home-theater system. Intended to replace VGA. DVI and HDMI cables. By supporting a maximum bandwidth of 32.4 Gbps. content up to 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution can be displayed

Features
Connector 1 form factor: Straight
Connector 2 form factor: Straight
Connector contacts plating: Gold
DisplayPort version: 1.4
Maximum resolution: 7680 x 4320 pixels
Supported graphics resolutions: 1920 x 1200 (WUXGA). 2560 x 1440. 3840 x 2160. 5120 x 2880. 7680 x 4320
Maximum refresh rate: 240 Hz
Feature: HDCP
HDCP version: 2.2
Feature: Display Stream Compression (DSC)
Cable length: 10 m
Connector 1: DisplayPort
Connector 2: DisplayPort
Connector 1 gender: Male
Connector 2 gender: Male
Product colour: Black
Feature: High Dynamic Range (HDR) supported
Bandwidth: 32400 MB/s
Feature: Multi-Stream Transport (MST)
Certificates
Compliance certificates: CE. RoHS
Sustainability
Feature: Sustainability compliance
Weight & dimensions
Weight: 500 g
Packaging data
Package width: 250 mm
Package depth: 15 mm
Package height: 335 mm
Package type: Polybag
Package weight: 520 g
Logistics data
Harmonized System (HS) code: 8544421900
Country of origin: China
Master (outer) case width: 300 mm
Master (outer) case length: 280 mm
Master (outer) case height: 490 mm
Master (outer) case gross weight: 6.2 kg
Products per master (outer) case: 10 pc(s)
