ACCESS POINTS

BE3600 WiFi 7 Wall
Plate Access Point for
Ultra-Fast Connectivity

Optimized Wired Performance
with 2.5G PoE Ports
With 2.5G PoE input and pass-through ports. along with two Gigabit RJ45 ports. enjoy high-speed data transfers and connect multiple devices to your gigabit network. Wired devices. such as IP Phones. can be powered without the need for additional electrical cables.

Seamless Integration into the Omada SDN
Remotely manage your access points. switches. and routers across multiple sites — all from a single interface.

Features
Feature: 2.4 GHz
Feature: 5 GHz
Maximum data transfer rate: 5012 Mbit/s
Maximum data transfer rate (2.4 GHz): 688 Mbit/s
Maximum data transfer rate (5 GHz): 2882 Mbit/s
Ethernet LAN data rates: 10.100.1000.2500 Mbit/s
Networking standards: IEEE 802.11a. IEEE 802.11ac. IEEE 802.11ax. IEEE 802.11b. IEEE 802.11be. IEEE 802.11g. IEEE 802.11n. IEEE 802.3at
Number of users: 250 user(s)
Feature: VLAN support
Feature: Airtime Fairness (ATF)
Feature: BeamForming
Security
Feature: MAC address filtering
Number of SSID supported: 16
Feature: Remote Authentication Dial-In User Service (RADIUS)
Feature: Access Control List (ACL)
Ports & interfaces
Ethernet LAN (RJ-45) ports: 3
Power
Feature: Power over Ethernet (PoE)
Power consumption (max): 17 W
Design
Placement: Ceiling. Wall
Product colour: White
Feature: Reset button
Feature: LED indicators
Antenna
Antenna type: Internal
Antennas quantity: 4
Antenna gain level (max): 5 dBi
Performance
Compatible operating systems: Microsoft Windows XP. Vista. Windows 7. Windows 8. Windows10. Windows 11. Linux
Certificates
Certification: FCC. RoHS
Weight & dimensions
Width: 86 mm
Depth: 40 mm
Height: 143 mm
Packaging data
Package type: Box
Packaging content
Quantity per pack: 1 pc(s)
Feature: Mounting kit
Operational conditions
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -40 - 70 °C
Storage relative humidity (H-H): 5 - 90%
