MONITORS

Optimized Brightness with Auto EcoView

The Auto EcoView function is a sensor on the front of the monitor that measures ambient light and optimizes the screen's brightness to a level akin to viewing a sheet of paper under typical office lighting conditions. Since the screen is never too bright. eye strain is reduced while power consumption is cut by up to 50% compared to operating the monitor with Auto EcoView turned off and set to the default factory brightness of 100%.

IPS Panel with Wide Viewing Angles

The IPS (in-plane switching) panel offers 178° viewing angles to minimize color shift and contrast when viewing the screen at an angle. This ensures stable and consistent display when two or more people view the screen at once or in a multi-monitor environment.

Three Inputs Including DisplayPort

DisplayPort. DVI-D 24-pin. and D-Sub mini 15-pin inputs are included for connection with various graphics boards.

Viewing Comfort with an Ergonomic Stand

Adjust the screen to the most comfortable position with 100 mm height adjustment. 30° tilt. 70° swivel. and 90° rotation for portrait mode. A stand with 30° tilt only is available as an option.

Reduced Blue Light

A preset mode called “Paper” adjusts the brightness. contrast ratio. and color temperature to simulate those of printed paper. Paper mode significantly reduces the amount of blue light emitted from the screen for more comfortable viewing.

Built to Last Five Years

EIZO’s five-year warranty is two years or 67% longer than the standard three-year warranty of most brands. Even if the initial purchase price of the FlexScan S1934 is higher than another 19-inch monitor. the TCO (total cost of ownership) will likely be lower due to the significantly longer buying cycle and less need for repair.

Optional LCD Panel Protector

The FP-1901 protector fits easily between the LCD screen and bezel. has a light transmission rate of more than 90%. and includes both an anti-glare coating side to reduce light reflection and a glossy side for crisper. more vibrant images.

Display
Display diagonal: 48.3 cm (19")
Display resolution: 1280 x 1024 pixels
HD type: SXGA
Native aspect ratio: 5:4
Display technology: LED
Panel type: IPS
Display brightness (typical): 250 cd/m²
Response time: 14 ms
Screen shape: Flat
Supported graphics resolutions: 1280 x 1024 (SXGA)
Contrast ratio (typical): 1000:1
Viewing angle. horizontal: 178°
Viewing angle. vertical: 178°
Display number of colours: 16.78 million colours
Pixel pitch: 0.293 x 0.293 mm
Horizontal scan range: 31 - 64 kHz
Vertical scan range: 55 - 61 Hz
Viewable size. horizontal: 37.5 cm
Viewable size. vertical: 30 cm
Viewable size diagonal: 48.1 cm
Feature: DDC/CI
Feature: Separate H/V sync
Multimedia
Number of speakers: 2
Feature: Built-in speaker(s)
Design
Product colour: Grey
Ports & interfaces
VGA (D-Sub) ports quantity: 1
Feature: DVI port
DVI-D ports quantity: 1
DisplayPorts quantity: 1
Headphone outputs: 1
Headphone connectivity: 3.5 mm
Feature: Microphone in
Feature: HDCP
Feature: AC (power) in
Ergonomics
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm
Feature: Height adjustment
Adjustable height (max): 10 cm
Feature: Pivot
Pivot angle: 0 - 90°
Feature: Swivelling
Swivel angle range: -35 - 35°
Feature: Tilt adjustment
Tilt angle range: 0 - 30°
Feature: On Screen Display (OSD)
On Screen Display (OSD) languages: Simplified Chinese. Traditional Chinese. German. English. Spanish. French. Italian. Japanese. Swedish
Number of OSD languages: 9
Power
Energy efficiency class (SDR): C
Energy consumption (SDR) per 1000 hours: 9 kWh
Power consumption (typical): 9.4 W
Power consumption (standby): 0.5 W
Power consumption (max): 21 W
Power consumption (off): 0.1 W
AC input voltage: 100 - 240 V
AC input frequency: 50 - 60 Hz
Energy efficiency scale: A to G
European Product Registry for Energy Labelling (EPREL) code: 346705
Operational conditions
Operating temperature (T-T): 5 - 35 °C
Operating relative humidity (H-H): 20 - 80%
Weight & dimensions
Width (with stand): 405 mm
Depth (with stand): 205 mm
Height (with stand): 506.5 mm
Weight (with stand): 5.6 kg
Width (without stand): 405 mm
Depth (without stand): 61.5 mm
Height (without stand): 334 mm
Weight (without stand): 3.8 kg
Packaging data
Feature: User Guide on CD-ROM
Packaging content
Feature: Stand included
Cables included: AC. Audio (3.5mm). DVI. VGA
Feature: Quick start guide
Sustainability
Sustainability certificates: ENERGY STAR
Other features
Display: LED
Feature: On/off switch
Certification: TCO. TUV/GS. RCM. CE. CB. cTUVus. FCC-B. ICES-003-B. TUV/S. VCCI-B. EPA Energy Star. RoHS. WEEE. RoHS. CCC. EAC
Logistics data
Harmonized System (HS) code: 85285210
