USB-C

Supports the following transmission types: Audio/Video/Data transmission/Charging function

- Supports data transfer rates of up to 40 Gbit/s
- Supports USB Power Delivery Revision 3.1 (PD 3.1) with 20 V. 5A and 240W
- Backwards-compatible with Thunderbolt 3. USB 3.2. USB 3.1 and USB 2.0
- Supports DisplayPort (2.0) video/audio signals and PCi Express
- Video/audio support up to 8K (7680 × 4320 pixels at 60 Hz)
- USB-IF certified

The 3rd generation DIGITUS® USB 4.0 cable with aluminum housing is an all-rounder among cables. Thanks to the Thunderbolt 3 protocol. it can be used for PCI Express. DisplayPort and Host-to-Host transfers. With this cable. you can transfer audio/video signals. data as well as power. The data transfer speed is 40 Gbit/s. which makes the transfer speed 8x faster than USB 3.0 (5Gbit/s). 4x faster than USB 3.1 (10 Gbit/s) and 2x faster than USB 3.2 (20Gbit/s). This allows you to transfer large quantities of data such as films and music within seconds. Video signals are transmitted max. in 8K with a display refresh rate of 60 Hz. In addition. it also supports the resolutions 5K (5120 x 2880) at 60 Hz and 4K (3840 x 2160) @60Hz (dual mode possible). Thanks to USB Power Delivery Revision 3.1. the fast charging function is ensured. With the corresponding charging device. you can charge your smart devices rapidly with max. 240 W (5 A / 48 V). The USB Type-C interface enables wide compatibility with devices with this connection.

Features
USB version: USB4 Gen 2x2
Connector 1: USB C
Connector 2: USB C
Connector 1 gender: Male
Connector 2 gender: Male
Connector 1 form factor: Straight
Connector 2 form factor: Straight
AWG wire size: 30
Connector material: Aluminium
Connector contacts plating: Gold
Feature: Magnetically shielded
Cable jacket material: Polypropylene
Cable jacket type: Extremely flexible
Maximum data transfer rate: 40000 Mbit/s
Maximum data transfer rate: 40 Gbit/s
Product colour: Black
Cable type: Round cable
Feature: Plug and Play
Feature: USB Power Delivery (USB PD)
USB Power Delivery revision: 3.0
USB Power Delivery up to: 100 W
Maximum resolution: 7680 x 4320 pixels
Maximum refresh rate: 60 Hz
Weight & dimensions
Cable length: 1 m
Cable diameter: 5 mm
Bend radius (min): 6 cm
Packaging data
Package width: 230 mm
Package depth: 55 mm
Package height: 20 mm
Package weight: 77.312 g
Packaging content
Quantity per pack: 1 pc(s)
Logistics data
Package volume: 253 cm³
UK Trade Tariff code: 85444290
Country of origin: China
